Facial Recognition & Analytics
- Face capture, comparison, and search
- Supports 16 libraries, up to 20,000 images (≤ 1 GB total)
- 1 channel face capture, 4 channel comparison alarms
Motion Detection
- 16-channel human/vehicle analysis
Video & Audio
- 16 IP channels, 160 Mbps in/out
- HDMI: up to 4K @30Hz
- VGA: up to 1080p @60Hz
- Independent HDMI/VGA output
- 1 RCA audio in/out, two-way audio supported
Decoding
- Formats: H.265+/H.264+
- Max resolution: 12 MP
- Playback: 16 channels
- AI on: up to 8-ch@1080p
- AI off: up to 12-ch@1080p
Network
- 128 remote connections
- Full protocol support (IPv4/IPv6, RTSP, HTTPS, etc.)
- Gigabit Ethernet (RJ-45 10/100/1000 Mbps)
Storage & Interfaces
- 2 SATA ports (up to 10 TB each)
- 2 USB 2.0 ports (front/rear)
- 4 alarm inputs, 1 output
General
- Power: 12 VDC, ≤15 W
- Temp: -10°C to 55°C
- Humidity: 10%–90%
- Size: 385 × 315 × 52 mm
- Weight: ≤ 1 kg (without HDD)
