Video & Audio
- Compression: H.264+/H.264, G.711u (audio)
- Analog Input: 16-ch BNC, supports HD-TVI/AHD/HDCVI/CVBS (up to 1080p30)
- IP Input: 2-ch (up to 18-ch), max 1.3MP
- Output: HDMI/VGA up to 1080p60
- Audio I/O: 1-ch RCA input/output, 2-way supported
Encoding & Playback
- Resolution: 1080p lite, 720p, WD1, CIF, etc.
- Frame Rate: Up to 30fps (CIF), 12fps (HD)
- Bit Rates: Video 32 Kbps–4 Mbps, Audio 64 Kbps
- Dual Stream: Supported
- Playback: 16-ch synchronous
Network & Storage
- Protocols: TCP/IP, DHCP, DDNS, NTP, HTTPS, etc.
- Remote Access: Up to 128 connections
- Storage: 1 SATA, up to 10TB
Interfaces & Power
- Network: 1 RJ45 (10/100M)
- USB: 2 × USB 2.0
- Power: 12 VDC, ≤ 20W (no HDD)
Physical
- Size: 285 × 210 × 45 mm
- Weight: ≤ 1.2 kg
- Temp/Humidity: -10°C to 55°C, 10%–90%
