Perimeter Protection
- Line Crossing/Intrusion Detection: 2-ch
- Enhanced VCA Mode: Up to 4-ch
Recording & Video
- Compression: H.265 Pro+/Pro/H.265/H.264+/H.264
- Resolution: Up to 8 MP (Lite & Full modes)
- Frame Rate: Up to 30 fps (CIF), 8 fps (8 MP)
- Bit Rate: 32 Kbps – 10 Mbps
- Dual Stream: Supported
- Playback: 4-ch synchronous
Inputs & Outputs
- Analog Input: 4-ch BNC (HDTVI/AHD/HDCVI/CVBS up to 8 MP)
- IP Input: 2-ch (up to 6-ch), Enhanced IP mode: 4-ch (up to 8-ch)
- Audio: 1-ch RCA input/output, 4-ch via coaxial, 2-way supported
- Video Output: HDMI/VGA up to 1080p60
Network & Storage
- Bandwidth: 96 Mbps total, 32 Mbps incoming (Enhanced IP)
- Remote Connections: Up to 32
- Protocols: TCP/IP, DHCP, DDNS, NTP, HTTPS, etc.
- Storage: 1 SATA, up to 6 TB
- USB: 2 × USB 2.0
General
- Power: 12 VDC, ≤ 15 W
- Temp/Humidity: -10°C to +55°C, 10%–90%
- Alarm I/O: Not available
